SW Commercial 100 Series Hinged Double Glazed Door

Thermal & Energy Performance
Performance related to insulation, comfort and energy efficiency
U Value: 3.7 – 4.3
SHGC: 0.28 – 0.52
Sound Insulation: 25-45 dB


Weather Performance
Performance under wind, rain and external conditions
Water Resistance: 150 Pa
Air Infiltration: 2.70-3.15 L/s.m²
Wind Load Rating: N5


Structural Details
Core construction and system specifications
Thermal Break: No (Non-Thermal Break System)
Frame Depth: 100 mm
Ultimate Strength: ±3000 Pa

Get Your Free Quote

Description

Frame Colours
Available in standard colours (black, white and grey), with custom finishes offered for large-scale projects

Glass Options
Low-E, obscured, fluted, laminated, grey and acoustic glass

Hardware
1. Legge 995 Narrow Style Multi Function Lock Set
2. Dorma SB2312 Narrow Style Multi Function Lock Set
3. Doric DS1295 Two Point Dead Lock & DS1600 Handle
4. Lockwood LW5782SS Selector
5. Doric DN7300&DN995 Commercial Locking
6. Auslock S31B Slim Smart
7. LOCKWOOD CTX6782 Auto Lock

Flyscreen
N/A

Variants
Inward/Outward

Configurations

Explore our standard size range and possible configurations to determine the most appropriate door for your home.
